| 型号 | F mm | D mm | A mm | C mm | 重量 kg/pc |
| 2.5×3 | 3 | 22 | 12 | 4.5 | 0.05 |
| 3.5×4 | 4 | 24 | 13 | 5.5 | 0.08 |
| 4×5 | 5 | 26 | 14 | 6.5 | 0.1 |
| 5×6 | 6 | 30 | 16 | 7.5 | 0.16 |
| 6×7 | 7 | 34 | 18 | 8.5 | 0.2 |
| 7×8 | 8 | 38 | 20 | 10 | 0.3 |
| 9×10 | 10 | 46 | 24 | 12.5 | 0.5 |
| 11×12 | 12 | 54 | 28 | 15 | 0.7 |
| 13×13 | 13 | 58 | 3o | 16 | 0.85 |
| 13×14 | 14 | 62 | 32 | 17.5 | 1 |
| 15×16 | 16 | 70 | 36 | 20 | 1.5 |
| 16×17 | 17 | 74 | 38 | 21 | 1.9 |
| 17×18 | 18 | 78 | 40 | 22 | 2.4 |
| 18×20 | 20 | 88 | 45 | 27 | 2.9 |
| 20×22 | 22 | 98 | 50 | 30 | 3.2 |
| 22×24 | 24 | 110 | 56 | a3 | 4.7 |
| 24×26 | 26 | 122 | 62 | 35 | 5.9 |
| 26×28 | 28 | 138 | 70 | 37 | 8 |
| 28×30 | 30 | 148 | 75 | 39 | 11 |
| 30x32 | 32 | 158 | 80 | 41 | 12.3 |
| 32x34 | 34 | 18B | 95 | 43 | 15.6 |
| 34×36 | 36 | 198 | 100 | 45 | 17.6 |
| 30×38 | 38 | 218 | 110 | 48 | 19.2 |
| 38×40 | 40 | 228 | 115 | 50 | 29.2 |
| 40×42 | 42 | 238 | 120 | 57 | 32 |
| 42×46 | 46 | 29a | 150 | 57 | 34 |
